| Customization: | Available |
|---|---|
| Type: | Sheet |
| Standard: | AISI, ASTM, DIN, JIS, GB, BS |
| Quantity: | |
|---|---|
Inconel 625
It mainly consists of nickel (Ni), with a significant amount, along with chromium (Cr) for corrosion resistance, molybdenum (Mo) to enhance strength and resistance to pitting and crevice corrosion, and niobium (Nb) which contributes to its high - temperature stability.
Properties
Corrosion Resistance: It offers outstanding resistance to a wide range of corrosive media, including seawater, various acids like sulfuric and phosphoric acids, and alkalis. This makes it ideal for marine and chemical processing applications.
High - Temperature Performance: Inconel 625 can maintain excellent mechanical properties at elevated temperatures, up to around 1093°C. It resists oxidation and creep, making it suitable for components in gas turbines and heat exchangers.
Mechanical Strength: The alloy has high strength and toughness, enabling it to withstand mechanical stress in demanding applications without deforming or fracturing easily.
Applications
It is widely used in industries such as aerospace for components like engine parts, in the oil and gas industry for pipelines and subsea equipment, and in the power generation sector for boiler components and superheaters. In summary, Inconel 625's combination of corrosion resistance, high - temperature performance, and mechanical strength makes it a crucial material in many high - tech and heavy - duty industries.
| Grades | UNS | Chemical Composition(wt.)% | |||||||||||||||||||||
| C | Cr | Ni | Ti | Fe | Co | Mn | Si | Mo | Cu | W | P | S | Al | Nb | V | B | Zr | N | O | Ce | |||
| Inconel 625 | N06625 | Max. | 0.1 | 23 | 0.4 | 5 | 1 | 0.5 | 0.5 | 10 | 0.4 | 4.15 | |||||||||||
| Min. | 20 | 8 | 3.15 | ||||||||||||||||||||
