ISO PED Nickel Alloy Pipe Tube Hastelloy C276 C22 B2 Manufacture

Product Details:
Place of Origin: China Jiangsu
Brand Name: Zhongxing (zxnialloy)
Certification: CE,ROHS
Model Number: Hastelloy C276 Tube

Payment & Shipping Terms:

Minimum Order Quantity: 5
Packaging Details: Hastelloy C276 Tube packed in wooden case for Hastelloy C276
Delivery Time: 5-20 Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 tons per month

Quantity:
Availability:





Get Best Price Add to Cart

inconel monel nickel alloy capillary tube hastelloy

Descriptions

Specifications

Company Profile

Process Flow

Product information

Best selling ISO PED Wholesale Nickel Alloy Pipe / Tube Hastelloy C276 C22 B2 manufacture

Features: Hastelloy C-276 has excellent resistance to localized corrosion, stress corrosion cracking, and to both oxidizing and reducing media, thus making it suitable for a wide variety of chemical process environments, including ferric and cupric chlorides, hot contaminated media (organic and inorganic), formic and acetic acids, seawater and brine solutions. It is one of the few materials that withstands the corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide.

Application

Some typical applications are:

Strong oxidizers (such as ferric and cupric chlorides)
Hot contaminated media (organic and inorganic)
Chlorine
Formic and acetic acids
Acetic anhydride
Seawater and brine solutions

Highlight:

Hastelloy C276 Tube,ISO PED Nickel Alloy Pipe,Hastelloy C276 C22 B2

Material:	Ni Cr Mo	Elongation:	30 %
Brinell Hardness HB:	≤220	Density:	8.89 G/cm3
Tensile Strength Rm N/mm²:	760MPA	Yieldstrength R P0. 2 N/mm²:	345MPA
Electrical Resistivity(24℃):	1.30 Microhm-m	Thermal Conductivity(32℃):	9.4 W/m-K
Product Name:	Hot Sale Industry Bright Annealing Hastelloy C276 Nickel Alloy Hastelloy C276 Round Tube

1.Chemical Properties of Hastelloy C276 Tube

Hastelloy Alloy

Ni

Cr

Co

Mo

FE

W

Mn

C

V

P

S

Si

C276

Balance

14.5-16.5

2.5 Max

15.0-17.0

4.0-7.0

3.0-4.5

1.0 Max

0.01 Max

0.35 Max

0.04 Max

0.03 Max

0.08 Max

2.Types we offer

ASTM	Alloy	Type	UNS	Misc./Shape
ASTM B574 Bar	Hastelloy C276	Nickel	N10276	Bar
ASTM B575 Plate	Hastelloy C276	Nickel	N10276	Plate
ASTM B575 Strip	Hastelloy C276	Nickel	N10276	Strip
ASTM B575 Sheet	Hastelloy C276	Nickel	N10276	Sheet
ASTM B619 Welded Pipe	Hastelloy C276	Nickel	N10276	Welded Pipe
ASTM B622 Seamless Tubing	Hastelloy C276	Nickel	N10276	Seamless Tubing
ASTM B366 Fittings	Hastelloy C276	Nickel	N10276	Fittings
ASTM B574 Wire	Hastelloy C276	Nickel	N10276	Wire

About Us

Jiangsu Zhongxing Nickel Alloy Co., Ltd. is a leading manufacturer specializing in the research, development, and production of seamless pipes and capillary coils. With a factory spanning 16,000 square meters, we offer a diverse range of products, including nickel alloys, high-temperature alloys, nickel-copper alloys, nickel-titanium alloys, Invar alloys, soft magnetic alloys, and other alloy materials.
